MODULITH TPU Feet
formerly GEN2Flexible feet that keep a tabletop build planted. A bottom row of one case takes them in the case's own underside slots; a row of two or more cases takes foot rails, and the feet go into the lower rail. Printed in TPU, or bought as adhesive rubber feet - one or the other, same count and same spots.
Installation guide: Tabletop Builds
How it works: Printing MODULITH
Shows the main printed body in its recommended print orientation - separate pieces (labels, accents) and removable print aids aren't included.
Flexible feet that keep a tabletop build planted. A bottom row of one case takes them in the case's own underside slots; a row of two or more cases takes foot rails, and the feet go into the lower rail. Printed in TPU, or bought as adhesive rubber feet - one or the other, same count and same spots.
| Print estimate | 1.9 g TPU · 12 minEstimated with a Prusa CORE One, 0.4 mm HF nozzle, 0.2 mm layer height. |
|---|---|
| Connects to | Case underside slots or the lower foot rail (tabletop) |
In the listing, look for TPU Foot in the file list. Same file everywhere it appears; if a kit includes it, either copy works.
Planning a whole build? The Planner lists every file your layout needs.
Installation guide: Tabletop Builds
How it works: Printing MODULITH
Technical details
STL file · 5 KB
Current
One part in this family
One file covers this part: TPU Foot (STL)
View the part - 3D preview, print orientation and specs
Works with this part
Universal - tabletop builds only: into the underside slots of a single bottom-row case, or into the lower foot rail when the bottom row has two or more cases. Printed TPU feet or adhesive rubber feet, one or the other - same count, same spots. Hanging and wall builds use none; the 59 collection has no tabletop option.
Required to use this part
One of these hosts
Snaps into the underside slots of a single bottom-row tabletop case - four per 1W, middle positions shared on wider cases; a 4W case is still one case.
Into the lower foot rail when a tabletop build's bottom row has two or more cases - counted for the whole row, never per rail piece.
Compatible alternatives or customization
Adhesive rubber feetPURCHASEDA one-for-one alternative: the same count at the same support spots, stuck to the flat pads around the slots instead of snapped in. A build carries one or the other, never both.
